Specification:
Item | Standard |
Operating condition | PN: 1.0/1.6 Mpa (10/16bar) |
The water temperature | cold water up to 50℃ and hot water up to 90℃ |
Standard | ISO 4064 Class B |
Material | Brass, Cast iron, Plastic |
Size | DN15 - DN50 |
Pressure loss | ΔP63 |
Application:
To totalize the total volume of water passing through the pipeline.
Features: Large measuring range; high flow accuracy; Steady error curve; Long life of service; Reliable operation; Magnetic shield protection; Negligible head loss at working flow-rates; Vacuum sealed register without any condensation problem. Upon request, the meter can be equipped with pulse output device.
Error curve: From qt inclusive up to and including qs is ±2%; From qmin inclusive up to but excluding qt is ±5%.
Packing: Carton + pallet.
